wika Miniature resistance thermometer For sanitary applications Model TR21-B for orbital welding
Applications
■■ Sanitary applications
■■ Food and beverage industry
■■ Bio and pharmaceutical industry, production of active ingredients
Special features
■■ Sensor can be calibrated without having to open the process
■■ Simple and fast connection using an M12 plug connector
■■ With direct sensor output (Pt100/Pt1000 in 3 or 4-wire version) or integrated transmitter with 4 ... 20 mA output signal, individually parameterisable with free-of-charge WIKAsoft-TT PC configuration software.
■■ Wetted parts from stainless steel 1.4435
■■ Self-draining and dead-space minimised, materials and surface finish qualities in accordance with standards of hygienic design
Description
The model TR21-B resistance thermometer provides temperature measurement in sanitary applications and can be used for the measurement of liquid and gaseous media in the range of -50 ... +250 °C. For application in hazardous areas, intrinsically safe versions are available. To integrate it into the process, the patented thermowell model TW61 (patent, property right applied for under no. DE 102010037994 and US 12 897.080) is directly orbitally welded into a pipeline. The connection ends are straight and prepared for orbital welding. The process connections meet the stringent requirements, in terms of materials and design, of hygienic measuring points. All electrical components are protected
against moisture (IP 67 or IP 69 K).The resistance thermometer is available with direct sensor output or integrated transmitter, which can be configured individually via the PC configuration software
WIKAsoft-TT. Measuring range, damping, error signalling per NAMUR NE43 and TAG no. can be adjusted. For easy calibration or maintenance, the sensor is removable without having to break into the process or disconnect the electrical connection. Thus hygiene risks can be minimised and downtimes can be reduced. The spring loading, integrated into the union nut, guarantees the contact between the sensor tip and the bottom of the thermowell and thus ensures a short response time and
lasting high accuracy. Insertion length, process connection, sensor and connection method can each be selected for the respective application within the order information. The electrical connection is
made via an M12 x 1 circular connector.
