Dwyer 2000--2025 Dwyer 2000--2030 Dwyer 2000--2040 Dwyer 2000--2050 Dwyer 2000--2060 Dwyer 2000--2080 made in USA

Bezel provides flange for flush mounting in panel.
Clear plastic face is highly resistant to breakage. Provides undistorted viewing of pointer and scale.
Precision litho-printed scale is accurate and easy to read.
Calibrated range spring is flat spring steel. Small amplitude of motion assures consistency and long life. It reacts to pressure on diaphragm. Live length adjustable for calibration.
Red tipped pointer of heat treated aluminum tubing is easy to see. It is rigidly mounted on the helix shaft.
Pointer stops of molded rubber prevent pointer over-travel without damage.
“Wishbone” assembly provides mounting for helix, helix bearings and pointer shaft.
Jeweled bearings are shock-resistant mounted; provide virtually friction-free motion for helix. Motion damped with high viscosity silicone fluid.


SPECIFICATIONS
Service: Air and non-combustible,
compatible gases (natural gas option
available). Note: May be used with
hydrogen. Order a Buna-N diaphragm.
Pressures must be less than 35 psi.
Wetted Materials: Consult factory.
Housing: Die cast aluminum case and
bezel, with acrylic cover. Exterior finish
is coated gray to withstand 168 hour salt
spray corrosion test.
Accuracy: ±2% of FS (±3% on -0,
-100PA, -125PA, -10MM and ±4% on
-00, -60PA, -6MM ranges), throughout
range at 70°F (21.1°C).
Pressure Limits: -20 in Hg to 15 psig†
(-0.677 to 1.034 bar); MP option: 35 psig
(2.41 bar); HP option: 80 psig (5.52 bar).
Overpressure: Relief plug opens
at approximately 25 psig (1.72 bar),
standard gages only.u
Temperature Limits: 20 to 140°F*
(-6.67 to 60°C). -20°F (-28°C) with low
temperature option.
Size: 4˝ (101.6 mm) diameter dial face.
Mounting Orientation: Diaphragm in
vertical position. Consult factory for other
position orientations.
Process Connections: 1/8˝ female NPT
duplicate high and low pressure taps -
one pair side and one pair back.
Weight: 1 lb 2 oz (510 g), MP & HP 2 lb
2 oz (963 g).
Standard Accessories: Two 1/8˝ NPT
plugs for duplicate pressure taps, two
1/8˝ pipe thread to rubber tubing adapter,
and three flush mounting adapters with
screws. (Mounting and snap ring retainer
substituted for three adapters in MP &
HP gage accessories.)
Agency Approvals: Meets the technical
requirements of EU Directive 2011/65/EU
(RoHS II). Note: -SP models not RoHS
approved.
Note: For applications with high cycle rate within gage total pressure rating, next
higher rating is recommended. See Medium and High pressure options.
*Low temperature models available as special options.
