Germany Wika pressure sensor A-10 Wika A-10 pressure transmitter

Germany Wika pressure sensor A-10 Wika A-10 pressure transmitter

Special features

■■ Measuring ranges from 0 … 0.6 to 0 … 1,000 bar

■■ Non-linearity 0.25 % or 0.5 %

■■ Output 4 ... 20 mA, DC 0 ... 10 V, DC 0 ... 5 V and others

■■ Electrical connection: Angular connector form A and C, circular connector M12 x 1, cable outlet 2 m

■■ Process connection G ¼ A DIN 3852-E, ¼ NPT and others

Description

The model A-10 pressure transmitter for general industrial applications is not only notable for its compact design, but it also offers excellent quality at an extremely competitive price. The user can choose between a non-linearity of 0.25 % and 0.5 %. A free test certificate provides information on the measuring points recorded during manufacture. The model A-10 is set up for worldwide use through the international cULus and GOST-R certification. The various pressure units and process connections required for particular operating conditions are available at short notice.

Product show
Germany Wika pressure sensor A-10 Wika A-10 pressure transmitter

Germany Wika pressure sensor A-10 Wika A-10 pressure transmitter
