Wika Ultra High Purity Attachable indicator with LED wika WUR-1
Applications
Semiconductor and flat panel industry Microelectronic Technology Gas distribution systems
(Gas sticks, gas panels, bulk-gas supply)

Special features
Top View or Front View
Up to 2 Switch points freely programmable
Ingress protection IP65
5 different units manually adjustable

Description
Dynamic
An unique solution for a local display of the process pressure offers the attachable indicator model WUR-1. With this especially for the UHP-Market designed indicator a signal and freely adjustable switch points can be transmitted simultaneously.

Due to its universal programmability and simple mounting the attachable indicator can also be easily installed on pressure transmitters which are already in use. Its scale can be fully adjusted directly on site without master instrument. Unit (psi, bar, kPa, MPa and kg/cm²), decimal point, display range, zero point and switch points can be adjusted via the control keys.

Comfortable
Power is directly supplied by the 4 ... 20 mA-loop, i.e. no extra power supply is required.

Practical
The seven millimetre high, red LED display is easy to read. In order to be able to adapt the indicator to the application, it is available in two different versions; Front View (connection to the transmitter at the bottom) or Top View (connection to the transmitter at the back).
