wika Pressure transmitter for precision measurements P-30 P-31

wika Pressure transmitter for precision measurements P-30 P-31

Applications

■■ Measurement and test benches

■■ Calibration technology

■■ Laboratories

■■ Plant construction and machine building

Special features

■■ Accuracy 0.1 %, without additional temperature error in a range of 10 ... 60 °C

■■ Optional accuracy of 0.05 % (full scale) available

■■ Fast measuring rates up to 1 kHz

■■ Analogue, USB and CANopen output signals available

■■ On-site calibration possible using product software

Description

Precise The model P-30 and P-31 pressure transmitters have been developed for precision measurements. Through the use of special WIKA pressure sensors, precision measurements with a maximum measuring deviation of as low as 0.05 % of span are guaranteed. As a result of their active temperature compensation, these pressure transmitters have no additional temperature error in the range of 10 ... 60 ° C. Fast The high measuring and output rates of up to 1 kHz make the measured value available as quickly as possible. Compact The compact design makes the pressure transmitter ideal for mounting into test benches, such as 19" racks.
