■■ Titanium case for especially high resistance (option)
Description
For the most demanding measurement tasks The model LH-20 submersible pressure transmitter has been designed for the most demanding of level measurement tasks. A slender design, highest accuracies, low temperature errors and an adjustable measuring range ensure the suitability of the LH-20 for all submerged level measurements. The model LH-20 submersible pressure transmitter can
adapt to countless applications and measuring media through a large number of features and options. Depending on the requirements, this submersible pressure transmitter is available with, amongst other things, a titanium case, PUR/ PE/FEP cable, 0.1 % accuracy, HART, scalability or parallel
temperature output signal. For operation in hazardous environments, the model LH-20 submersible pressure transmitter is also available in an intrinsically safe version. For potable and fresh water applications, a potable water conformant product variant is possible in
accordance with KTW and ACS.
Hermetically sealed, robust and durable
The model LH-20 submersible pressure transmitter has been engineered for use in the harshest environments. Through a double, redundant sealing concept, it is permanently hermetically
sealed. A robust design from stainless steel or titanium, with a spring-reinforced cable seal, ensures a long service life, even under the big mechanical loads of installation and continuous use.
Designs with the highest media resistance using FEP cable and titanium cases, along with the integrated lightning protection, guarantee the longevity of the submersible pressure transmitter even under the most adverse environmental influences in aggressive media, in both indoor and
outdoor use.
