Wika Flush diaphragm pressure gauge For sanitary wika 432.55 stainless steel

Wika Flush diaphragm pressure gauge For sanitary applications wika 432.55 stainless steel

Applications

■■ Process industry: Biotechnology and pharmaceutical industries, cosmetics manufacturing, food industry

■■ Quick cleaning of measuring point, without residue

■■ For gaseous and liquid aggressive media that are highly viscous or crystallising, also in aggressive ambience

Special features

■■ Dry measuring cell, no transmission fluid

■■ Flush, welded diaphragm

■■ Suitable for SIP and CIP

■■ Wetted parts and enclosing metallic components from stainless steel

■■ Scale ranges from 0 … 0.6 bar

Description

The model 432.55 pressure gauge is designed to meet

special demands on the process connections in the food and

beverage, biotechnology and pharmaceutical industries.

Due to the design of the gauge it is possible to use

an absolutely dry measuring cell, thus excluding a

contamination of the medium with transmission fluids that

may, for example, occur on diaphragm seal systems in the

case of a damage to the diaphragm.

The complete instrument is made of high-grade stainless

steel. Due to the flush welded diaphragm element the

connection to the process is free of dead space.

Design

EN 837-3

Nominal size in mm

100, 160

Accuracy class

1.6

Scale ranges

0 ... 0.6 to 0 ... 10 bar (0 ... 10 to 0 ... 150 psi)

or all other equivalent vacuum or combined pressure and

vacuum ranges

Pressure limitation

Steady: Full scale value

Fluctuating: 0.9 x full scale value

Short time: 1.5 x full scale value

Permissible temperature

Ambient: -20 … +60 °C

Medium: -20 … +150 °C

Temperature effect

When the temperature of the measuring system deviates

from the reference temperature (+20 °C):

max. ±0.8 %/10 K of full scale value

Ingress protection

IP 54 per EN 60529 / lEC 529
