Bourdon tube pressure gauge Test gauge series class 0.1 wika 342.11

Bourdon tube pressure gauge Test gauge series class 0.1 wika 342.11

Applications

■■ For gaseous and liquid media that are not highly viscous or crystallising

■■ Precision measurement in laboratories

■■ Highest-accuracy pressure measurement

■■ Testing and calibration of industrial type pressure gauges

Special features

■■ Knife edge pointer and dial with mirror band scale for

optimal accuracy of reading

■■ Precise movement with wear parts of argentan

■■ Particularly easy-to-read scale due to nominal size 250

■■ Scale ranges up to 0 … 1600 bar

Description

Design

per EN 837-1, including transport case and acceptance test

certificate (individual listing of the calibration points)

Nominal size in mm

250

Accuracy class

0.1

Scale ranges

0 ... 1.0 to 0 ... 1600 bar

or all other equivalent vacuum or combined pressure and

vacuum ranges

Adjustment medium

≤ 25 bar: Gas

> 25 bar: Oil
