| Storage temperature | -58° to 203°F (-50 to 95°C) |
| Operating ambient Temperature |
-58 to 203°F (-50 to 95°C). Set point shifts less than 1% of range for a 50°F Temperature (28°C) ambient temperature change. Slight ambient effects for 25-50’ extra capillary length on temperature switch models, consult factory. |
| Media temperature |
Pressure models: Sensor types 2, 7, 9: -50 to 400°F (-45 to 204°C) Sensor types 3, 4, 8: -20 to 200°F (-28 to 93°C) Sensor types 5, 6: 0 to 320°F (-18 to 160°C) Sensor type P: 0 to 200°F (-18 to 93°C); 20 to 250°F (-7 to 121°C) for optional Viton sensor Differential pressure models: Sensor type K: 0 to 180°F (-18 to 82°C); 20 to 250°F (-7 to 121°C) for optional Viton sensor Temperature models: See model chart. |
| Set point Repeatability |
Temperature models: ±1% of adjustable range Pressure models: Sensor types 2, P: ±1.5% of adjustable range Sensor types 3-9: ±1% of adjustable range Differential pressure models: K1 to K3: ±1%, K4 to K6: ±1.5% of adjustable range |
| Shock |
Differential pressure and temperature models: set point repeats after 15 G’s, 10 millisecond duration Pressure models: Set point repeats after 75 G’s, 10 milliseconds |
| Vibration |
Differential pressure and temperature models: Set point repeats after 2.5 G’s, 10-2000 Hz. Pressure models: Set point repeats after 15 G’s, 10-2000 Hz |
| Enclosure | 316 stainless steel |
| Enclosure classification |
Certified to Enclosure Type 4X Class I, Division 1 product meets enclosure Type 7; Class II, Division I product meets enclosure type 9. Certified to IP66 requirements |
| Switch output |
Code S: One SPDT, hermetically sealed. Code D: Two SPDT for DPDT action, hermetically sealed |
| Electrical ratings |
Code H: 5 A at 125/250 VAC, 5 A resistive and 3 A inductive at 28 VDC. Silver contacts Code L: 1 A at 125 VAC, 1 A resistive and 0.5 A inductive at 28 VDC Bifurcated gold contacts |
| Electrical Connection |
Code N: 1/2" NPT (male) with 72" leadwires Code M: M20 metric threads, 72" leads Option M515, 4 terminal DIN connector (DIN 43650 Form A) available SPDT only (does not meet Div. 1 or 2, or ATEX requirements.) |
| UE 12SLSN2 | UE 12SLSN3 | UE 12SLSN4 | UE 12SLSN5 | UE 12SLSN6 | UE 12SLSN7 | UE 12SLSN8 | UE 12SLSN9 | UE 12SLSNP |
| UE 12SLDN2 | UE 12SLDN3 | UE 12SLDN4 | UE 12SLDN5 | UE 12SLDN6 | UE 12SLDN7 | UE 12SLDN8 | UE 12SLDN9 | UE 12SLDNP |
| UE 12SLDM2 | UE 12SLDM3 | UE 12SLDM4 | UE 12SLDM5 | UE 12SLDM6 | UE 12SLDM7 | UE 12SLDM8 | UE 12SLDM9 | UE 12SLDMP |
| UE 12SLSM2 | UE 12SLSM3 | UE 12SLSM4 | UE 12SLSM5 | UE 12SLSM6 | UE 12SLSM7 | UE 12SLSM8 | UE 12SLSM9 | UE 12SLSMP |
| UE 12SHSN2 | UE 12SHSN3 | UE 12SHSN4 | UE 12SHSN5 | UE 12SHSN6 | UE 12SHSN7 | UE 12SHSN8 | UE 12SHSN9 | UE 12SHSNP |
| UE 12SHSM2 | UE 12SHSM3 | UE 12SHSM4 | UE 12SHSM5 | UE 12SHSM6 | UE 12SHSM7 | UE 12SHSM8 | UE 12SHSM9 | UE 12SHSMP |
| UE 12SHDN2 | UE 12SHDN3 | UE 12SHDN4 | UE 12SHDN5 | UE 12SHDN6 | UE 12SHDN7 | UE 12SHDN8 | UE 12SHDN9 | UE 12SHDNP |
| UE 12SHDM2 | UE 12SHDM3 | UE 12SHDM4 | UE 12SHDM5 | UE 12SHDM6 | UE 12SHDM7 | UE 12SHDM8 | UE 12SHDM9 | UE 12SHDMP |
