| STORAGE TEMPERATURE | -65 to 160°F (-54 to 71°C) |
| AMBIENT TEMPERATURE LIMITS |
-58 to 160°F (-50 to 71°C); models 36-39, 520-525, 540-548, 701-705: 0 to 160°F (-17 to 71°C); Types 820E, 822E: -40 to 160°F (-40 to 71°C) set point typically shifts less than 1% of range for a 50°F (28°C) ambient temperature change; less than 2% for types E121& E122 |
| SET POINT REPEATABILITY |
Temperature models: ±1% of adjustable range Pressure models 126-164, S126B-S164B, 171-174, 270-274, 358-376, 520-535, 540-543, 560-564, 701-705: ±1% of adjustable range; models 450-559: ±1/2% of adjustable range; models 36-39, 183-194, 483-494, 544-548, 565-567, 612-680: ±1 1/2% of adjustable range |
| SHOCK | Set point repeats after 15 G, 10 millisecond duration |
| VIBRATION | Set point repeats after 2.5 G, 5-500 Hz |
| ENCLOSURE |
Die cast aluminum (max. 0.4% copper), epoxy powder coated; gasketed; coverlock; internal set point lock standard on types J, C, F; gasketed aluminum tamper-resistant dial cover on types B, H, E; aluminum nameplate |
| ENCLOSURE CLASSIFICATION |
Certified to enclosure type 4X. Types 820E, 822E; designed to meet NEMA 4 requirements with option M300; Class I, Division 1 product meet enclosure type 7; Class II, Division 1 products meet enclosure type 9. Certified to IP66 requirements |
| SWITCH OUTPUT |
One or two SPDT; dual switch may be separated up to 100% of range; except type 822E where switch #2 can be set up to 25% of range span below switch #1 setpoint; switches may be wired “normally open” or “normally closed”. Two SPDT hermetic sealed switches available on H122P models |
| ELECTRICAL RATING |
15 A 125/250/480 VAC resistive (standard) except types H122P; 11A 125/250 VAC resistive; B121-13272, B122-13322, E121-13273, E122-13321; 22A 480VAC resistive |
| REFERENCE SCALES | Types B, E & H: external dial. Scale divisions vary with range. |
| J120-520 | J120-560 | J120-183 | J120-488 | J120-193 | J120-156 | J120-702 | J120-552 | ||
| J120-521 | J120-561 | J120-184 | J120-489 | J120-194 | J120-164 | J120-703 | J120-553 | ||
| J120-522 | J120-562 | J120-185 | J120-S126B | J120-490 | J120-356 | J120-704 | J120-554 | ||
| J120-523 | J120-563 | J120-186 | J120-S134B | J120-491 | J120-358 | J120-705 | J120-555 | ||
| J120-524 | J120-564 | J120-188 | J120-S137B | J120-492 | J120-361 | J120-706 | J120-15834 | ||
| J120-525 | J120-565 | J120-189 | J120-S144B | J120-493 | J120-376 | J120-450 | J120-15835 | ||
| J120-530 | J120-566 | J120-483 | J120-S152B | J120-494 | J120-270 | J120-451 | J120-15836 | ||
| J120-531 | J120-567 | J120-484 | J120-S156B | J120-126 | J120-274 | J120-452 | J120-15837 | ||
| J120-532 | J120-171 | J120-485 | J120-S164B | J120-134 | J120-612 | J120-453 | J120-15838 | ||
| J120-533 | J120-172 | J120-486 | J120-190 | J120-137 | J120-616 | J120-454 | J120-15839 | ||
| J120-534 | J120-173 | J120-191 | J120-144 | J120-680 | J120-550 | ||||
| J120-535 | J120-174 | J120-192 | J120-152 | J120-701 | J120-551 | ||||
.jpg)
