UE H100-521 Pressure switch

UE H100 521 Buna-N diaphragm  original USA made Pressure switch

Pressure, Vacuum, Differential Pressure and Temperature Switches
1.The 100 Series is a costeffective pressure and temperature switch for process plants and OEM equipment.
The rugged, one piece enclosure features a slanted cover for wiring accessibility.
2.A wide variety of microswitch and processconnection options make this versatile series ideal for applications
requiring a rugged weather-proof mechanical switch.
3.Typical applications that utilize the 100 Series are heat tracing, freeze protection, processing equipment
(pumps, compressors),  inputs for annunciator panels, and fire suppression systems.
Product Overview
Rugged, NEMA 4X, epoxy coated enclosure
SPDT or DPDT switch output
Easy access wiring
Single switch output
Internal reference scale and adjustable deadband available
Adjustable ranges: 30 "Hg Vac to 5000 psi
       • 1 bar Vac to 344 bar
       • 0.2 "wcd to 500 psid
       • 0,5 mbar d to 34,5 bar d
       • -180 to 650 ºF
       • -117 to 340ºC
Approvals: UL, CSA, CE, TUV
