| STORAGE TEMPERATURE | -65 to 160°F (-54 to 71°C) |
| AMBIENT TEMPERATURE LIMITS |
-58 to 160°F (-50 to 71°C); models 36-39, 520-525, 540-548, 701-705: 0 to 160°F (-17 to 71°C); Types 820E, 822E: -40 to 160°F (-40 to 71°C) set point typically shifts less than 1% of range for a 50°F (28°C) ambient temperature change; less than 2% for types E121& E122 |
| SET POINT REPEATABILITY |
Temperature models: ±1% of adjustable range Pressure models 126-164, S126B-S164B, 171-174, 270-274, 358-376, 520-535, 540-543, 560-564, 701-705: ±1% of adjustable range; models 450-559: ±1/2% of adjustable range; models 36-39, 183-194, 483-494, 544-548, 565-567, 612-680: ±1 1/2% of adjustable range |
| SHOCK | Set point repeats after 15 G, 10 millisecond duration |
| VIBRATION | Set point repeats after 2.5 G, 5-500 Hz |
| ENCLOSURE |
Die cast aluminum (max. 0.4% copper), epoxy powder coated; gasketed; coverlock; internal set point lock standard on types J, C, F; gasketed aluminum tamper-resistant dial cover on types B, H, E; aluminum nameplate |
| ENCLOSURE CLASSIFICATION |
Certified to enclosure type 4X. Types 820E, 822E; designed to meet NEMA 4 requirements with option M300; Class I, Division 1 product meet enclosure type 7; Class II, Division 1 products meet enclosure type 9. Certified to IP66 requirements |
| SWITCH OUTPUT |
One or two SPDT; dual switch may be separated up to 100% of range; except type 822E where switch #2 can be set up to 25% of range span below switch #1 setpoint; switches may be wired “normally open” or “normally closed”. Two SPDT hermetic sealed switches available on H122P models |
| ELECTRICAL RATING |
15 A 125/250/480 VAC resistive (standard) except types H122P; 11A 125/250 VAC resistive; B121-13272, B122-13322, E121-13273, E122-13321; 22A 480VAC resistive |
| REFERENCE SCALES | Types B, E & H: external dial. Scale divisions vary with range. |
| UE B121-120 | UE B121-121 | UE C120-120 | UE C120-121 | UE E121-2BSA |
| UE E121-2BSB | UE E121-3BS | UE E121-4BS | UE E121-5BS | UE E121-8BS |
| UE F120-1BS | UE F120-2BS | UE F120-3BS | UE F120-4BS | UE F120-5BS |
| UE F120-6BS | UE F120-7BS | UE F120-8BS | UE 820E-1BS | UE 820E-2BS |
| UE 820E-3BS | UE 820E-4BS | UE 820E-5BS | UE 820E-6BS | UE 820E-7BS |
| UE 820E-8BS | UE 822E-1BS | UE 822E-2BS | UE 822E-3BS | UE 822E-4BS |
| UE 822E-5BS | UE 822E-6BS | UE 822E-7BS | UE 822E-8BS |
