| Switch output | One SPDT snap action switch; switch may be wired “normally open” or “normally closed” |
| Electrical rating |
15A 125/250/480 VAC resistive except for H100-15623, 15731-15737, 15884, 20A 125/250/480 VAC resistive, B100-13546 and E100-13545, 22A/480 VAC. Electrical switches have limited DC capabilities at 24-30 VDC, 2A resistive and 1A inductive. 125 VDC, 0.5A resistive, 0.03A inductive. Consult factory for additional information. |
| Weight | 2-7 lbs; Varies with model |
| Electrical connection |
1/2” NPT (female); Two 7/8” diameter knockouts |
|
THERMOWELL S** For all bulb & capillary switches, except Model 13545 |
|
Brass W075 SD6225-75 1⁄2” NPT with 3⁄” NPT adapter bushing, 4” BT W191 SD6225-191 1⁄” NPT, 4” BT W118 SD6225-118 1⁄” NPT with 3⁄” NPT adapter bushing, 7” BT W192 SD6225-192 1⁄” NPT, 7” BT 316 Stainless Steel W076 SD6225-76 3⁄” NPT, 4.5” BT W193 SD6225-193 1⁄” NPT, 4.5” BT W119 SD6225-119 3⁄” NPT, 7.5” BT W177 SD6225-177 1⁄” NPT, 7.5” BT For all immersion stem switches; except Model 13546 W139 SD6225-139 3⁄4” NPT X 1-23/32” BT, BRASS W140 SD6225-140 3⁄” NPT X 1-23/32” BT, 316 ST/ST |
.jpg)
