Features
• UL listed and cUL certified. CE compliant to low voltage directive and pressure equipment directive
• Vacuum, Pressure or Differential pressure measurement
• 5 A @ 125/250 VAC SPDT snap-acting switch
• External stainless steel multi-turn adjusting screw
• OEM capabilities include external adjustment knob with or without reference scale

Technology
The 24 Series (Delta Pro™) was designed to be a compact, cost-effective differential pressure switch for applications such as proof-of-flow, filter monitoring, etc. It depends upon two opposing diaphragms to sense pressure on the "High" and "Low" pressure outputs of a system. The resulting pressure differential is transmitted through a linkage to a snap-action electrical switch, providing an output when a pre-set difference is exceeded. This set point can be easily modified while under pressure via an external adjusting screw. This adjustment "pre-loads" the actuation mechanism, which results in excellent vibration-resistance. Straight pressure and vacuum versions, with a single diaphragm, are also available.

Storage Temperature	-20° to 180°F (-29° to 82°C)
Ambient Temperature	30° to 160°F (-1° to 71°C). Set point typically shifts less than ±0.6% of range for a 50°F (28°C) ambient temperature change; consult factory for special ratings
Max Media Temperature	200°F (93°C) at 100 psi working pressure
Shock	Set point repeats after 15G, 10 millisecond duration
Vibration	Set point repeats after 2.5G, 5-500 Hz
Enclosure Classification	Complies with enclosure type 4 requirements with optional water tight conduit connector. Reinforced polyester body, stainless steel cover with gasket.
Set Point Repeatability	Typically ± 1% of full scale range.
Switch Output	One SPDT precision snap-acting micro-switch with mechanical contact life of 10 million cycles. Actual life depends on electrical load and cycle frequency
Electrical Rating	Rated to 5 A resistive and 5 A inductive (75% PF) at 125 VAC and 250 VAC, 1/4 HP; 5 A resistive and 3 A inductive at 30 VDC and 0.5 A resistive and 0.25 inductive at 125 VDC. Gold flash over silver contacts for minimum loads of 5 mA at 6 VDC, 2mA at 12 VDC and 1 mA at 24 VDC
Weight	6.5 oz.
Electrical Connection	7/8" hole for optional 1/2" NPT conduit connector. Terminal block with screw terminals. Max wire size 16 AWG
Pressure Connection	Models 013-014, 019-022: 1/4" NPT (female) brass; models 011-012, 015-018: 1/4" NPS (female) FDA compliant* Udel® polysulfone, non-tapered to minimize connection stress with 1/4" NPT (male) fittings - max torque is 2-ft.lbs.
Mounting & Installation	Surface mount with two screws through clearance holes, or mount by pressure connections
