Weight |
Temperature models: approximately 1 lb 14 oz. (0,85 kg)
Pressure models: approximately 12 ounces (0,34 kg)
Differential models: approximately 3 lb (1,4 kg) |
|
Temperature Assembly |
Non-toxic oil fill; 6 feet 304 stainless steel. Optional lengths available |
|
Temperature deadband |
Typically 2% of range under laboratory conditions
(70°F ambient circulating bath at a rate of 1/2°F per minute change) |
|
Pressure Connection |
1/2" NPT (female) or 1/4" NPT (female).
Differential pressure: 1/8" NPT (female)
Optional pressure connections available, see page 11. |
|
MOUNTING |
Pressure: May be pipe mounted or bracket mounted using kit 62169-13
Differential Pressure: Should be mounted using 2 mounting holes on sensor bracket
Temperature: Mounting kit 62169-13 should be specified for new installations |
