Pivot Seal Pressure Detectors for Fluid Power Applications

They are rugged, field-mounted instruments that incorporate a flexible modular design providing cost effective sensing solutions. The pressure sensing element of the Pivot Seal pressure detector is a force-balance, piston-actuated assembly sealed by an o-ring. As with all SOR pressure detectors, the actual motion of the piston to actuate the micro detector is only several thousandths of an inch, resulting in minimal o-ring wear. Media pressure on the area of the piston counteracts the force of the range spring (adjustable by the adjusting nut screw) and moves the piston shaft and the force transmitter to directly actuate the electrical snap-action detecting element.

Application Information

The design of the piston/port assembly results in the device being well-suited for a wide variety of high pressure fluid power (hydraulic) applications, especially where high-shock pressures and high-cycle rates are expected, and where normal industrial clean hydraulic fluid is used.
