USA made  SOR CO 101AG - EF3 - N4 - C1A SOR 101AG - EF45 - N4 - C1A SOR 121AG - EF45 - N4 - C1A

Application Information

Basic models with standard wetted parts are normally suitable for air, oil, water and non-corrosive process
fluids. See the Quick Selection Guide on page 4. Corrosive service and special requirements may require
optional components. See How to Order on page 3. Series 101/121 differential pressure detects are or
suited for low-to-high differential pressure, fluid power or process applications where high and varying static pressures, high overrange, proof, shock pressure or cycle rates are expected.

Model Number Range
(psid)
Typical Dead
Band (psi)
Electrical
Rating
Electrical
Connection
Housing
Material
101NN - K3 - N4 -C1A 3 to 30 0.5 15 amps
24 volt
3/4” NPT(F) Aluminum
101NN - K45 - N4 - C1A 10 to 75 1.5
121NN - K45 - N4 - C1A 75 to 500 10
101L - K3 - N4 - C1A 3 to 30 0.5 15 amps
24 volt
3/4” NPT(F) Cast Iron
101L - K45 - N4 - C1A 10 to 75 1.5
121L K45 - N4 - C1A 75 to 500 10
101AG - EF3 - N4 - C1A 3 to 30 1.0 15 amps
24 volt
1/2”
NPT(M)
Aluminum
101AG - EF45 - N4 - C1A 10 to 75 3.0
121AG - EF45 - N4 - C1A 75 to 500 20

Product Specifications
Pressure Port 1/4” NPT(F)
Maximum Working Pressure
101       500 psi
121      1,000 psi
Wetted Materials
Diaphragm Teflon-Coated Polyimide
O-Ring Buna-N
Pressure Connection 316SS; CF-8M Cast Alloy
Product Specifications
Design and specifications are subject to change without notice.
For latest revision, see www.sorinc.net.
