Stock SOR 16RB-K2-N4-F1A Original SOR 16S-K2-N4-F1A SOR 16RB-K5-N4-F1A SOR 16S-K5-N4-F1A

Applications
Opposed piston differential pressure detectors in this catalog are suitable for a variety of process
and fluid power applications. Specific application requirements can normally be met by selecting
optional components, such as detecting elements, diaphragm systems and pressure ports. Certain
applications may require customized specials. Consult the factory or the SOR representative in your
area. General purpose, weathertight and conventional explosion proof models are presented in this
catalog. Refer to Forms 388 and 468 for models with hermetically sealed detecting element capsules
for use in hazardous locations and extremely harsh environments, or when system (static) pressure
varies significantly.

15RB-EE2-N4-C2A 101RN-EE3-N4-CIA-TT 9NN-K45-M4-C1A
6NN-KK3-N4-F2A-TT 4NN-KK4-N4-B2A-TT 121NN-K45-N4-C1A 17RB-K2-M4-C1A-TT BH-011001-011
99V-K45-N4-B1A 5NN-K45-N4-C1A 9NN-K45-N4-C1A 1RN-K45-M4-C2A-TT 54NN-K188-N4-B1A-TT
BH-016022-016 52NN-K116-N4-C1A BH0-048015-048 BH-048005-048 BH-048004-048 414822-QBI039
44V1-BB4-M1-C1A 5AC-AD45-M2-F1A BH-016026-016 107AL-N12-P1-F1A-C4 101NN-K3-N4-C1A-XX
17RB-K2-N4-C1A-TT 9NN-KK45-M4-C2A-TT 6NN-K5-N4-F1A-PP 5B4-K45-M4-C2A-TTCL 4B4-K4-M4-C2A 101LC-KK45-N4-C1A 201L-KK125-U9-C7A 701K1-U-P8-C-00/371U-1.16-C3A 403212-SA1ZP1
318642-SA1ZF3 54NN-KK118-N4-C1A 54NN-KK118-N4-C1A-TT 18RB-K5-M4-B1A 4RN-K5-M4-C1A-TT
541246-SA0K36 414824-SA1ZF2 397290-SA1ZJ2 121NN-K45-N4-C1A-CSTT 54NN-KK118-N4-C1A
107EL-EG12-P0-F1A-TT 12LC-EE45-M2-C2A-TT 6B3-EG3-M4-C2A-TT 6B3-EG45-N4-C2A-TTVVX
221A-A1B-B-A4-S3-X 107AL-N12-P1-F1A-TTX 4B3-K45-M4-C2A-CLTT 9B3-AA5-N4-C2A-CLC5TTYY
55V1-K45-N4-B1A 99V1-K45-N4-B1A 99V1-K5-N4-B1A 107AL-N40-P1-F0A 107AL-N12-P1-F0A-XD
55V-K45-N4-B1A 99V-K45-N4-B1A 12L-K45-N4-B1A 12L-K5-N4-B1A 6NN-K3-N4-F1A 6NN-K45-N4-C1A
54NN-EE5-N4-C2A 12NN-YY4-M4-B1A 54NN-EE118-N4-C2A 64NN-K3-M4-B1A-TT 107AL-N40-P1-F1A

Weathertight
Model Number		 Adjustable Range
(increasing differential pressure)
psid		 Typical Dead Band
psi		 Explosion Proof
Model Number
18RB-K2-N4-B1A 0.5 to 2.0 0.15 18S-K2-N4-B1A
18RB-K5-N4-B1A 0.5 to 12.0 0.2 18S-K5-N4-B1A
15RB-K2-N4-B1A 2.5 to 8.0 0.6 15S-K2-N4-B1A
15RB-K5-N4-B1A 3 to 50 0.6 15S-K5-N4-B1A
17RB-K2-N4-B1A 4 to 15 1.2 17S-K2-N4-B1A
17RB-K3-N4-B1A 5 to 60 1.0 17S-K3-N4-B1A
17RB-K5-N4-B1A 5 to 100 1.5 17S-K5-N4-B1A
14RB-K2-N4-F1A 8 to 30 2.5 14S-K2-N4-F1A
14RB-K5-N4-F1A 15 to 150 2.5 14S-K5-N4-F1A
13RB-K2-N4-F1A 15 to 60 5.0 13S-K2-N4-F1A
13RB-K5-N4-F1A 35 to 375 6.0 13S-K5-N4-F1A
16RB-K2-N4-F1A 60 to 150 20 16S-K2-N4-F1A
16RB-K5-N4-F1A 100 to 1000 20 16S-K5-N4-F1A
Piston Number
18
15
17
14,13
16		 Maximum System Pressure
20 psi
125 psi
500 psi
1000 psi
2000 psi		 Proof Pressure
400 psi
1000 psi
1000 psi
2500 psi
2500 psi
