SOR 14RB-K5-N4-F1A SOR 14S-K5-N4-F1A SOR 13RB-K2-N4-F1A SOR 13S-K2-N4-F1A SOR 13RB-K5-N4-F1A SOR 13S-K5-N4-F1A

Quick Selection Guide
Basic Opposed Piston Differential Pressure Detectors with standard wetted parts are normally
suitable for air, oil, water and non-corrosive process applications in hazardous locations and hostile
environments. Refer to the Quick Selection Guide section on page 4. Corrosive service and particular
customer requirements may require optional components. Refer to How to Order below to build a
customized model number or the dedicated page to locate optional components, such as: detecting
elements, diaphragm systems, pressure ports and accessories. Each position in the model number,
except Accessories, must have a designator.
Weathertight
Model Number
Adjustable Range
(increasing differential pressure)
psid
Typical Dead Band
psi
Explosion Proof
Model Number
18RB-K2-N4-B1A 0.5 to 2.0 0.15 18S-K2-N4-B1A
18RB-K5-N4-B1A 0.5 to 12.0 0.2 18S-K5-N4-B1A
15RB-K2-N4-B1A 2.5 to 8.0 0.6 15S-K2-N4-B1A
15RB-K5-N4-B1A 3 to 50 0.6 15S-K5-N4-B1A
17RB-K2-N4-B1A 4 to 15 1.2 17S-K2-N4-B1A
17RB-K3-N4-B1A 5 to 60 1.0 17S-K3-N4-B1A
17RB-K5-N4-B1A 5 to 100 1.5 17S-K5-N4-B1A
14RB-K2-N4-F1A 8 to 30 2.5 14S-K2-N4-F1A
14RB-K5-N4-F1A 15 to 150 2.5 14S-K5-N4-F1A
13RB-K2-N4-F1A 15 to 60 5.0 13S-K2-N4-F1A
13RB-K5-N4-F1A 35 to 375 6.0 13S-K5-N4-F1A
16RB-K2-N4-F1A 60 to 150 20 16S-K2-N4-F1A
16RB-K5-N4-F1A 100 to 1000 20 16S-K5-N4-F1A
Piston Number
18
15
17
14,13
16
Maximum System Pressure
20 psi
125 psi
500 psi
1000 psi
2000 psi
Proof Pressure
400 psi
1000 psi
1000 psi
2500 psi
2500 psi
