The Opposed Piston Type Differential Pressure Detector

is essentially two Static “O” Ring type pressure sensors connected at opposite ends of a common piston shaft. Housings are weathertight or explosion proof. Detecting elements are SPDT or DPDT. See Principle

on page 2.

Application Information

Basic models with standard wetted parts are normally suitable for air, oil, water and noncorrosive process fluids. See the Quick Selection Guide on page 4. Corrosive service and particular user requirements may require optional components. See How to Order on page 3. Operating performance of the opposed piston

type is optimized when system pressure is relatively constant. Process or fluid power applications that have high and varying static pressures, high over-range, proof, shock pressures or cycle rates may require a model from the 102/103 series. Design and specifications are subject to change without notice.
