Features of the Rosemount Annubar Flowmeter include:
Specifications:
| Fully Integrated Flowmeter |
Emerson Rosemount 3051SFA with Measurement Types 1-4 |
|
| Accuracy |
•Mass flow up to 0.8% of mass flow rate, 14:1 turndown •Classic MV up to ±0.85 % of flow rate, 8:1 flow turndown |
•Volumetric flow up to 0.8% of volumetric flow rate, 14:1 turndown •Classic MV up to ±0.85% of volumetric flow rate, 8:1 turndown |
| Repeatability | ± 0.1 % | ± 0.1 % |
| Output |
•4-20mA signal based on HART® Communication •WirelessHART with Smart Wireless THUM adapter |
•4-20mA signal based on HART® Communication •WirelessHART •FOUNDATION™ fieldbus |
| Long Term Stability | Up to 15-year stability | Up to 15-year stability |
| Warranty | Up to 15-year limited warranty | Up to 15-year limited warranty |
| Diagnostics |
•User-writable process temperature sensor limits •Sensor Temperature as an output •Instant Flow Verification |
advance HART diagnostics |
| Line Size |
2-in. to 8-in. (50 to 200 mm) – Sensor Size 1 6-in. to 36-in. (150 to 900 mm) – Sensor Size 2 12-in. to 72-in. (300 to 1800 mm) – Sensor Size 3 |
2-in. to 8-in. (50 to 200 mm) – Sensor Size 1 6-in. to 36-in. (150 to 900 mm) – Sensor Size 2 12-in. to 72-in. (300 to 1800 mm) – Sensor Size 3 |
