Absolute pressure transmitters Rosemount 3051CA country of origin Singapore

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.

Additionally, the Rosemount 3051C smart pressure transmitter has an installed five-year stability of ±0.125% demonstrating the ability to maintain performance over a five year period under the most demanding process conditions. The high accuracy and stability of the 3051C equates to reduced variability, lower operating and maintenance costs, and improved plant safety.


Transmitter output
A 4-20mA with digital signal based on Hart Protocol
F FOUNDATION fieldbus Protocol
W Profibus PA protocol
X Wireless (requires wireless options and engineered polymer housing)
M Low-power, 1-5Vdc with digital signal based on Hart protocol

output: 4-20 mA with digital signal based on HART Protocol; Low Power, 1-5 V dc with digital signal based on HART Protocol; Low power, 0.8-3.2 V dc with digital signal based on HART Protocol, optional
range: 0-0.01 in H2O to 0-2000 psid
accuracy: 0-1: +/-0.1% of span
power: 4-20 mA: 10.5-55 V dc with no load Low Power: 6-12 V dc with no load
materials: Sensor Wetted Parts: SST, Hastelloy, Monel, Tantalum
fluid: Sensor fill fluid: Silicone, Inert (Halocarbon)
mounting: Coplanar and Traditional flanges and Adapters: Cadmium and Nickel-plated CS, 316 SST
