 Rosemount 3051CA5A22A1AB4M5I5Q4Q8HR5 Rosemount made in Singapore

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.

Output options available to the Rosemount 3051C smart pressure transmitter include 4-20mA or 1-5VDC with HART protocol, Profibus, or FOUNDATION fieldbus. The Rosemount 3051C smart pressure transmitter offers so many options that it can be configured for any application.


3051CD Differential pressure transmitter
3051CG Gage pressure transmitter
3051CA Absolute pressure transmitter
code Pressure range
3051CD 3051CG 3051CA
0 -3----3inH2O/0.1inH2O Not present Not present
1 -25---25inH2O/0.5inH2O -25—25inH2O/0.5inH2O 0—30psia/0.3psia
2 -250—250inH2O/2.5inH2O -250—250inH2O/2.5inH2O 0—150psia/1.5psia
3 -1000—1000inH2O/10inH2O -407-1000inH2O/10inH2O 0—800psia/8psia
4 -300—300psi/3psi -14.7—300psi/3psi 0—4000psia/40psia
5 -2000—2000psi/20psi -14.7—2000psi/20psi Not present
code Output
A 4—20ma,with HART agreement digital signal
M 1—5Vdc,with HART agreement digital signal
F FF fieldbus
W profibus
code Structure parts material
Process flange type Flange material Liquid/gas discharge valve Flange joint material
5 coplanar Electroplate carbon steel Stainless steel Electroplate carbon steel
2 Coplanar Stainless steel Stainless steel Stainless steel
3 coplanar Hastelloy C Hastelloy C Hastelloy C
4 Coplanar Monel Monel Monel
8 coplanar Electroplate carbon steel Hastelloy C Electroplate carbon steel
7 coplanar Stainless steel Hastelloy C Stainless steel
0 Replace flange
code Diaphragm material
2 316L stainless steel
3 Hastelloy C
4 Monel
5 Tantalum
6 Gold plated monel
7 Gold plated stainless steel

3051CA1A02A1AB1H2L4M5 3051CA2A02A1AB1H2L4M5 3051CA3A02A1AB1H2L4M5
3051CA4A02A1AB1H2L4M5 3051CA5A02A1AB1H2L4M5 3051CA1A02A1AB3H2L4M5
3051CA2A02A1AB3H2L4M5 3051CA3A02A1AB3H2L4M5 3051CA4A02A1AB3H2L4M5
3051CA5A02A1AB3H2L4M5 3051CA1A02A1AB1H2L4M5K5 3051CA2A02A1AB1H2L4M5K5
3051CA3A02A1AB1H2L4M5K5 3051CA4A02A1AB1H2L4M5K5 3051CA5A02A1AB1H2L4M5K5
3051CA1A02A1AB1H2L4M5E5 3051CA2A02A1AB1H2L4M5E5 3051CA3A02A1AB1H2L4M5E5
3051CA4A02A1AB1H2L4M5E5 3051CA5A02A1AB1H2L4M5E5 3051CA1A02A1AB1H2L4M5I5
3051CA2A02A1AB1H2L4M5I5 3051CA3A02A1AB1H2L4M5I5 3051CA4A02A1AB1H2L4M5I5
3051CA5A02A1AB1H2L4M5I5 3051CA1A02A1AB3H2L4M5K5 3051CA2A02A1AB3H2L4M5K5
