Rosemount 3051CG2A22A1AB4M5DF Rosemount gauge pressure transmitter

Rosemount 3051CG2A22A1AB4M5DF Rosemount gauge pressure transmitter

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.

Output options available to the Rosemount 3051C smart pressure transmitter include 4-20mA or 1-5VDC with HART protocol, Profibus, or FOUNDATION fieldbus. The Rosemount 3051C smart pressure transmitter offers so many options that it can be configured for any application.

3051CD	Differential pressure transmitter
3051CG	Gage pressure transmitter
3051CA	Absolute pressure transmitter
code	Pressure range
	3051CD		3051CG		3051CA
0	-3----3inH2O/0.1inH2O		Not present		Not present
1	-25---25inH2O/0.5inH2O		-25—25inH2O/0.5inH2O		0—30psia/0.3psia
2	-250—250inH2O/2.5inH2O		-250—250inH2O/2.5inH2O		0—150psia/1.5psia
3	-1000—1000inH2O/10inH2O		-407-1000inH2O/10inH2O		0—800psia/8psia
4	-300—300psi/3psi		-14.7—300psi/3psi		0—4000psia/40psia
5	-2000—2000psi/20psi		-14.7—2000psi/20psi		Not present
code	Output
A	4—20ma,with HART agreement digital signal
M	1—5Vdc,with HART agreement digital signal
F	FF fieldbus
W	profibus
code	Structure parts material
	Process flange type	Flange material		Liquid/gas discharge valve		Flange joint material
5	coplanar	Electroplate carbon steel		Stainless steel		Electroplate carbon steel
2	Coplanar	Stainless steel		Stainless steel		Stainless steel
3	coplanar	Hastelloy C		Hastelloy C		Hastelloy C
4	Coplanar	Monel		Monel		Monel
8	coplanar	Electroplate carbon steel		Hastelloy C		Electroplate carbon steel
7	coplanar	Stainless steel		Hastelloy C		Stainless steel
0	Replace flange
