Rosemount 3051CG1A02A1AB1H2L4M5I5 CO CQ Rosemount Vietnam Rosemount Iran

Rosemount 3051CG1A02A1AB1H2L4M5I5 CO CQ Rosemount Vietnam Rosemount Iran

Advanced pressure transmitter with a flexible Coplanar platform and unmatched long-term stability and reliability
The Rosemount 3051C smart pressure transmitter combines advanced technology with the versatile Coplanar ™ process connection to create a new standard in pressure measurement technology. Even under the most demanding conditions, the performance specifications of the Rosemount 3051C smart pressure transmitter provide unmatched long-term stability and reliability

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.

Model		Transmitter type
3051C		Coplanar Pressure Transmitter
Measurement type
D		Differential
G		Gage
A		Absolute
Pressure range
	Differential (3051CD)	Gage (3051CG)	Absolute (3051CA)
1	–25 to 25 inH2O (-62,16 to 62,16 mbar)	–25 to 25 inH2O (-62,16 to 62,16 mbar)	–300 to 300 psi (-20.68 to 20.68 bar)
2	–250 to 250 inH2O (-621,60 to 621,60 mbar)	–250 to 250 inH2O (-621,60 to 621,60 mbar)	0 to 150 psia (0 to 10,34 bar)
3	–1000 to 1000 inH2O (-2.48 to 2.48 bar)	–393 to 1000 inH2O (-0.97 to 2.48 mbar)	0 to 800 psia (0 to 55.15 bar)
4	–300 to 300 psi (-20.68 to 20.68 bar)	–14.2 to 300 psi (-0.97 to 20.68 bar)	0 to 4000 psia (0 to 275.79 bar)
5	–2000 to 2000 psi (-137.89 to 137.89 bar)	-14.2 to 2000 psi (-0.97 to 137.89 bar)	N/A
0	–3 to 3 inH2O (-7.460 to 7.46mbar)	N/A	N/A
