Stock Rosemount 3051CG guage pressure transmitters 3051 Q4 Q8

Advanced pressure transmitter with a flexible Coplanar platform and unmatched long-term stability and reliability
The Rosemount 3051C smart pressure transmitter combines advanced technology with the versatile Coplanar ™ process connection to create a new standard in pressure measurement technology. Even under the most demanding conditions, the performance specifications of the Rosemount 3051C smart pressure transmitter provide unmatched long-term stability and reliability

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.

Specification:

output: 4-20 mA with digital signal based on HART Protocol; Low Power, 1-5 V dc with digital signal based on HART Protocol; Low power, 0.8-3.2 V dc with digital signal based on HART Protocol, optional
range: 0-0.01 in H2O to 0-2000 psid
accuracy: 0-1: +/-0.1% of span
power: 4-20 mA: 10.5-55 V dc with no load Low Power: 6-12 V dc with no load
materials: Sensor Wetted Parts: SST, Hastelloy, Monel, Tantalum
fluid: Sensor fill fluid: Silicone, Inert (Halocarbon)
mounting: Coplanar and Traditional flanges and Adapters: Cadmium and Nickel-plated CS, 316 SST
