Emerson Rosemount certificate of origin certificate of quality Rosemount 3051CD

Emerson Rosemount certificate of origin certificate of quality Rosemount 3051CD

Rosemount 3051C Coplanar Pressure Transmitters are the industry standard for Differential, Gage, and Absolute pressure measurement. The Coplanar Platform enables seamless integration with manifolds, flow and level solutions. Capabilities include: Power Advisory can proactively detect degraded electrical loop integrity issues (Option Code DA0)
Local Operator Interface with straightforward menus and built-in configuration buttons (Option Code M4) Safety Certification (Option Code QT)

Advanced pressure transmitter with a flexible Coplanar platform and unmatched long-term stability and reliability
The Rosemount 3051C smart pressure transmitter combines advanced technology with the versatile Coplanar ™ process connection to create a new standard in pressure measurement technology. Even under the most demanding conditions, the performance specifications of the Rosemount 3051C smart pressure transmitter provide unmatched long-term stability and reliability

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.

Model		Transmitter type
3051C		Coplanar Pressure Transmitter
Measurement type
D		Differential
G		Gage
A		Absolute
Pressure range
	Differential (3051CD)	Gage (3051CG)	Absolute (3051CA)
1	–25 to 25 inH2O (-62,16 to 62,16 mbar)	–25 to 25 inH2O (-62,16 to 62,16 mbar)	–300 to 300 psi (-20.68 to 20.68 bar)
2	–250 to 250 inH2O (-621,60 to 621,60 mbar)	–250 to 250 inH2O (-621,60 to 621,60 mbar)	0 to 150 psia (0 to 10,34 bar)
3	–1000 to 1000 inH2O (-2.48 to 2.48 bar)	–393 to 1000 inH2O (-0.97 to 2.48 mbar)	0 to 800 psia (0 to 55.15 bar)
4	–300 to 300 psi (-20.68 to 20.68 bar)	–14.2 to 300 psi (-0.97 to 20.68 bar)	0 to 4000 psia (0 to 275.79 bar)
5	–2000 to 2000 psi (-137.89 to 137.89 bar)	-14.2 to 2000 psi (-0.97 to 137.89 bar)	N/A
0	–3 to 3 inH2O (-7.460 to 7.46mbar)	N/A	N/A

Materials of construction
	Process flange type	Flange material	Drain/vent
2	Coplanar	SST	SST
3	Coplanar	Cast C-276	Alloy C-276
4	Coplanar	Alloy 400	Alloy 400/K-500
5	Coplanar	Plated CS	SST
7	Coplanar	SST	Alloy C-276
8	Coplanar	Plated CS	Alloy C-276
0	Alternate Process Connection

Models

3051CD0A02A1AB1H2L4M5E5 3051CD1A02A1AB1H2L4M5E5 3051CD2A02A1AB1H2L4M5E5 3051CD3A02A1AB1H2L4M5E5 3051CD4A02A1AB1H2L4M5E5 3051CD5A02A1AB1H2L4M5E53051CD0A02A1AB1H2L4M5I5 3051CD1A02A1AB1H2L4M5I5 3051CD2A02A1AB1H2L4M5I5 3051CD3A02A1AB1H2L4M5I5 3051CD4A02A1AB1H2L4M5I5 3051CD5A02A1AB1H2L4M5I5

3051CD0A02A1AB3H2L4M5K5 3051CD1A02A1AB3H2L4M5K5 3051CD2A02A1AB3H2L4M5K5 3051CD3A02A1AB3H2L4M5K5 3051CD4A02A1AB3H2L4M5K5 3051CD5A02A1AB3H2L4M5K53051CD0A02A1AB3H2L4M5E5 3051CD1A02A1AB3H2L4M5E5 3051CD2A02A1AB3H2L4M5E5 3051CD3A02A1AB3H2L4M5E5 3051CD4A02A1AB3H2L4M5E5 3051CD5A02A1AB3H2L4M5E53051CD0A02A1AB3H2L4M5I5 3051CD1A02A1AB3H2L4M5I5 3051CD2A02A1AB3H2L4M5I5 3051CD3A02A1AB3H2L4M5I5 3051CD4A02A1AB3H2L4M5I5 3051CD5A02A1AB3H2L4M5I
