Rosemount 3051S Scalable MultiVariable transmitter

The Rosemount 3051S MultiVariable Transmitter delivers unprecedented performance and capabilities by providing superior flow calculations including fully compensated mass or volume, energy, and totalized flow. Specify the level of compensation that best matches the application:

 Gas, natural gas, and steam measurement: Utilize full compensation (differential pressure, line pressure, and temperature measurement)

 Saturated steam: Utilize differential and line pressure, or differential pressure and temperature measurement

 Liquids: Utilize differential pressure and temperature measurement

 Liquids at stable temperatures: Utilize differential pressure measurement

 4-20 mA HART, WirelessHART, FOUNDATION Fieldbus protocols

Specifications:

Measurement Type	MultiVariable Measurement
Output	HART®, WirelessHART®
Reference Accuracy	Flow: ±0.65% Flow Accuracy over 14:1 Flow Turndown Differential Pressure: ±0.04% of DP Reading and 200:1 DP Turndown Absolute & Gage Pressure: ±0.055% of span and 200:1 Rangedown Process Temperature RTD Interface: ±0.67 ºF (0.37 ºC) - Sensor Matching enabled by Callendar-Van Dusen constants
Long Term Stability	10-year stability
Warranty	15-year limited warranty
Varialbles	Mass, Volumetric, and Energy Flow Totalized Flow Differential Pressure Static Pressure (Gage and Absolute) Process Temperature
Available	Fully Compensated Mass and Energy Flow
Calculation Types	Direct Process Variable Output
Available	Differential Pressure, Static Pressure, Process Temperature
Measurement	Differential Pressure and Static Pressure
Combinations	Differential Pressure and Process Temperature Differential Pressure
Configuration	Rosemount 3051SMV Engineering Assistant 6
