| Flush Flanged Seal (FFW) | ||
| Usual Application: |
General Application (Larger Line Sizes) |
|
| Process Connection Sizes: |
2 in. ⁄ DN 50 ⁄ 50A 3 in. ⁄ DN 80 ⁄ 80A 4 in. ⁄ DN 100 ⁄ 100A |
|
| Flanged Remote Seal (RFW) | ||
| Usual Application: |
General Application (Smaller Line Sizes) |
|
| Process Connection Sizes: |
½ in. ⁄ DN 15 ¾ in. 1 in. ⁄ DN 25 ⁄ 25A 1½ in. ⁄ DN 40 ⁄ 40A |
|
| Extended Flanged Seal (EFW) | ||
| Usual Application: | Viscous/Plugging Processes |
|
| Process Connection Sizes: |
1½ in. ⁄ DN 40 ⁄ 40A 2 in. ⁄ DN 50 ⁄ 50A 3 in. ⁄ DN 80 ⁄ 80A 4 in. ⁄ DN 100 ⁄ 100A |
|
| Threaded Remote (RTW) | ||
| Usual Application: | High Pressure Applications |
|
| Process Connection Sizes: |
¼ - 18 NPT ½ - 14 NPT ¾ - 14 NPT 1¼ - 11.5 NPT 1½ - 11.5 NPT |
|
| Hygienic Tri-Clamp (SCW) | ||
| Usual Application: | Hygienic Applications |
|
| Process Connection Sizes: |
1½ in. 2 in. 2½ in. 3 in. 4 in. |
|
| Hygienic Tank Spud (SSW) | ||
| Usual Application: | Hygienic Applications |
|
| Process Connection Sizes: |
1½ in. 2 in. 2½ in. 3 in. 4 in |
|
| Complete Seal Offering (PDF @ 6.4 Mb) | ||
Connection Types
| Direct Mount Coplanar | ||
| Connection Lengths: |
No Extension (0 mm) 2-inch (50 mm) 4-inch (100 mm) |
|
| Connection Types: |
Repairable-Welded All Welded Vacuum |
|
| Capillary | ||
| Capillary Length: | 1 ft (0.3 m) to 49.2 ft (15 m) |
|
| Capillary Material: |
316 SST armored sleeving PVC Coating on 316 SST armored sleeving 316 armored sleeving, support tube without compression fitting PVC coating on 316 armored sleeving, support tube with compression fitting |
|
| Direct Mount Inline | ||
| Connection Length: |
No extension 4-inch (100 mm) Thermal Optimizer |
|
