Measurement Type

Differential, gage, absolute, flow, and level

Output

WirelessHART®

Reference Accuracy

±0.025% of span

Total Performance

±0.1% of span

Long Term Stability

15-year stability

Warranty

15-year limited warranty

Power Module Life

1 minute update rate – 10 years

Update Rate

User selectable from 1 second to 60 minutes

Process Alerts

4 user configurable alerts: HI-HI, HI, LO, LO-LO

Rangedown

200:1

Antenna Options

10.0 dBm EIRP / 10 mW - 750 ft (230m)
12.5 dBm EIRP / 18 mW
16.0 dBm EIRP / 40 mW 2/3 mile (1km)

Emerson Rosemount 3051S Wireless Series of Instrumentation

1. Innovative SuperModule™ Platform

  2. Omindirectional External Wireless Antennas

• Improve connectivity to remote areas with expanded integral and remote antenna options enabling wireless communication of up to 1km (2/3 mi) between devices
• 10.0 dBm EIRP / 10 mW - 750 ft (230m)
• 12.5 dBm EIRP / 18 mW
• 16.0 dBm EIRP / 40 mW 2/3 mile (1km)

• View transmitter and diagnostic information easily
• Gain greater insight into connection status to WirelessHART network with intuitive bar graph
• See parameter status with internal diagnostics button

• Get the only wireless power solution optimized for both user and process safety
• Field replaceable – intrinsically safe
• 10-year power module at 1 minute update rate
• Alert for low power – indicates power module needs replacement
• HART communicator connection terminals
