What if you could
Maximize production output through tighter control of your tall towers and vessels?
Simplify installation and reduce maintenance routines?
Gain additional process insight?
Maximize production output through tighter control
Improve performance by reducing temperature effects
Enable direct mounting to taller vessels and distillation towers for a 90% reduction in response time (<1s digital response time)
Simplify installation and reduce maintenance
Remove the headaches of heat tracing and impulse piping
Improve reliability by replacing mechanical components with a digital architecture
Gain additional process insight
Get visibility to the individual pressure readings from each sensor as well as a scaled output for tank level or volume
Eliminate the need to buy a separate transmitter to monitor and control blanket pressure
Boost Your Results with a Digital Upgrade to a Proven Technology
The Rosemount 3051S Electronic pressure sensor System is a flexible, 2-wire, 4-20 mA HART architecture that calculates differential pressure (DP) using two pressure sensors that are linked together digitally.
Ideal applications for the Rosemount 3051S ERS System include tall vessels and distillation columns that have traditionally required excessive lengths of impulse piping or capillary.
Key Specifications
Reference Accuracy = ±0.025% of span
Measured variables = DP, P-Hi, P-Lo, Scaled Variable (level or volume)
4-20 mA HART Output
Max cable length = 150 feet (45 meters)
