USA CCS 611GZE explosion proof pressure switch

USA CCS 611GZE explosion proof pressure switch

CCS 611GZE Standard Features:
External Parts:
Stainless Steel
Construction
U.L./CSA
Explosion Proof:
Div. 1, 2
NEMA: 4, 7, 9, 13
Low Range
AMBIENT TEMP. RANGE
–30° to 160° F
–34° to 71° C
ENCLOSURE/CERTIFICATIONS:
Div. 1 explosion–proof and hermetically
sealed electrical assembly Part No.
46–1058 (46–1061 for “M” model option),
listed by both Underwriter’s Laboratories,
Inc. (File No. E32961) and CSA Testing
Laboratories (File No. 22921) for hazardous
locations, Class 1, Groups A, B, C, and D;
Class 2 Groups E, F, and G.
Options Code:
“7008” Gold Contacts
“7052” Exp. Proof w/3’ Leads
“7054” Exp. Proof w/6’ Leads
“7065” Teflon Wire
