USA CCS Vacuum Pressure Switch 604GVZ2-7011

USA CCS Pressure Switch 604GVZ2-7011

Standard Features of 604GVZ2:
•All models shown are Underwriters’ Laboratories, Inc.
listed in the Recognized Components Index, Guide
NKPZ “Motor Controllers, Float and Pressure Operated,”
File No. E72038.
• NEMA 4, 13
• Weatherproof
• Internal Case Ground
• Fire Resistant Steel Body
Ambient Temp. Range:
-30°F to +160°F or
-34°C to +71°C.
Note:
*Models 604GZM1 has an approximate dead band of 0.9 psi.
How to Order :
1. Specify model number.
2. Specify optional feature by inserting the letter designation
of the feature after the last letter in the model
number. Examples: 604GZF1 or 604GZF1-7011.
